Material: 100% Acrylic
Operating temperature: 125°C to 140°C.
Working conditions: The Acrylic filter bag is used in dust filtration systems/dry dust recovery systems, with good chemical resistance at high temperatures.
At VIFICO, customers will receive support for surveys, consultations, and free sample provision.
All filter fabrics are imported 100% from reputable suppliers with quality assurance, and have been carefully selected. VIFICO provides full import documentation including CO and CQ.
The dust filter bags are produced on European-standard manufacturing lines, achieving a capacity of over 20,000 products per month with a team of workers who have many years of experience in the industry.
Features
The Acrylic dust filter bag is made from non-woven dust filtration fabric with the chemical name acrylonitrile, capable of withstanding temperatures from 125°C to 140°C, with high abrasion resistance and excellent hydrolysis resistance.
Acrylic is widely used in Vietnam for producing dust filter bags for cement grinding, steel production, thermal power plants, and powdered detergents.
Examples:
- Acrylic dust filter bags effectively recover/treat common industrial dust.
- For highly adhesive dust, the Acrylic bag is treated with a moisture-resistant surface.
- For fine dust <2.5 microns, acidic or alkaline, requiring low emission concentration, choose Acrylic filter fabric made from fibers with small diameter, fabric weight from 550 - 600g/m², treated with PTFE membrane...
Applications
In Vietnam, Acrylic dust filter bags can be used in all industries that generate dust in certain positions or throughout all manufacturing processes such as:
- Construction materials industry: Cement, Steel, Gypsum, Tiles...
- Mining and mineral processing industry: Limestone powder, Sand, Glass, Aluminum, Non-ferrous metals...
- Animal feed and food industry, Pharmaceuticals, Tobacco
- Other industries: Wood, Fertilizers, Batteries, Tires, Plastics, Waste treatment, Boilers, Thermal power plants, Hot asphalt concrete...
Sizes of Acrylic dust filter bags:
- Diameters D110mm, D115mm, D120mm, D125mm, D130mm, D133mm, D135mm, D140mm; D148mm, D150mm, D155mm, D160mm, D165mm.
- Lengths: 1000mm, 1200mm, 1500mm, 2000mm, 2500mm, 3000mm, 3500mm, 4000mm, 5000mm, 5500mm, 6000mm, 8000mm.
- Some currently popular sizes of Acrylic dust filter bags: D130x1500mm, D130x2000mm, D135x2500mm, D140x3500mm, D155x6000mm
| Construction | Needle punch felt |
| Fiber Composition | 100% Acrylic |
| Scrim Composition | Acrylic |
| Felt Area Weight (g/m2) | 500, 550, 600 |
| Thickness (mm) | 2.2 - 2.6 mm |
| Mean Air Permeability (L/m².S@200Pa) | 150 - 250 |
| Breaking Strength-MD/warp (N/5x20cm) | 800 |
| Breaking Strength-CMD/weft (N/5x20cm) | 1000 |
| Shrinkage at 150oC within 90 min (%) | <2.0 |
| Operating Temperatures Recommended Maximum Continuous (oC) |
125 |
| Recommended Maximum Surge (oC) | 140 |
| Finish | Heat set, singed, calendared W/O Repellent, Membrane PTFE. |
